BOLT
DIA. |
INSERT
LENGTH (L) |
COIL
LENGTH (A) |
COIL
HEIGHT (B) |
WIRE
DIA. (D) |
LEG
LENGTH (W) |
SWL
TENSION (LBS.) |
WEIGHT (LBS.) |
BOX QTY |
3/4" |
3" |
1-3/4" |
1-5/8" |
.306" |
7-1/8" |
2,500 |
0.7 |
100 |
1" |
4" |
2-1/16" |
1-7/8" |
.306" |
9-1/2" |
3,500 |
1 |
50 |
1-1/4" |
4" |
2-1/16" |
2-1/4" |
.375" |
9-3/4" |
4,000 |
1.2 |
50 |
1-1/2" |
4" |
2-1/16" |
2-1/2" |
.375" |
10" |
4,000 |
1.4 |
50 |
